Service



Reefer Container

Kyowa Shipping, a leading company of the ocean transportation in the islands of Pacific Ocean, has provided liner shipping service for more than 40 years. In recent years, we are expanding the reefer transport business. We can offer reefer service which can maintain cargo at -40℃(THERMO KING Magnum Plus) or -60℃(THERMO KING SuperFreezer) while temperature can be controlled ranging from -25℃ to 25℃ by ordinary reefer units. As a pioneer in the carriage of Reefer container in the region, we keep on sailing to better support customer needs.

Specifications
Type 20'R 20'RH 40'RH
Internal Dimensions L 5,449mm 5,450mm 11,590mm
W 2,290mm 2,290mm 2,280mm
H 2,271mm 2,581mm 2,537mm
Door Openings W 2,294mm 2,294mm 2,290mm
H 2,264mm 2,569mm 2,569mm
Internal Cubic Capacity 28.3m³ 32.2m³ 67.0m³
Tare Weight 3,120kg 2,960kg 4,650kg
Max Payload 27,360kg 27,520kg 30,350kg
Max Gross Weight 30,480kg 30,480kg 35,000kg

*above dimensions are for reference only. Actual dimensions may vary within container series.

container
container
Remarks

*Please handle container with care when you stuff your cargo.
*Please wash and clean the inside immediately after using. In some cases, your cargo may cause corrosive gas
 and it affects the unit.
